Vacuum planetary defoaming Mixer 2000 series

  • Admin
  • 2024-06-06
  • 45 times

Main use

  • For the research and invention of new materials in universities and scientific research institutes;

  • New energy battery

  • nanomaterials

  • IC semiconductor

  • Solar photovoltaic

  • biomedicine

  • Photoelectric component

  • LED and touch screen

  • Daily chemical

......

Product details

Vacuum planetary defoaming mixer 2000 series, under the action of nearly 100-400G centrifugal gravity and relative vacuum degree 0/-100Kpa working environment, non-contact container stirring, defoaming;

The gravity separation motion of the mixed material along the vector direction and the upward pushing effect of the material's own weight will separate the bubbles with smaller density and play the role of defoaming; At the same time, the material rotates in the container cup, so that the different groups of materials in the cup are fully cross-mixed under vacuum, and finally achieve nanoscale defoaming and stirring mixing; Making it easy to stir and defoam previously unmanageable or time-consuming high-viscosity liquids; Easy mixing/dispersion between liquids, between liquids and powders, filling ratios and materials with large specific gravity differences! 2000 series to provide customers with material mixing batch production equipment;

modelHybrid processing capabilitiesCentrifugal forceMaxRevolution Max.RPMRevolution/rotation speed ratioDynamic balanceRelative vacuumApplications
By qualityBy volume
VDB-2000≤2000g*2≤600ml*2350G1300ConstantDouble cups on both sides with equal weight0/-100kpaNormal neutral substances
VDB-200OH≤1000g*2≤600ml*2400G1800ConstantDouble cups on both sides with equal weight0/-100kpaNormal neutral substances
VDB-2000AC≤2000g*2≤600ml*2350G1300ConstantDouble cups on both sides with equal weight0/-100kpaStrong corrosive substances


*If the parameter display is incomplete, swipe left and right!
